Vending fleet: telemetry and remote support
A machine 400 km away stops selling. This is the software chain that tells you why without sending a technician.
- Area
- Mobile apps and connected machines
- Written
- 2026
- Built with
- Embedded Android
- Kotlin
- MQTT
- Node.js
- PostgreSQL
- React
Inside this project
The problem
A vending or kiosk operator has three separate blind spots. The machine knows what happened but keeps it locally. The payment provider knows a card was charged but not whether anything came out of the slot. The support line has neither, so every ambiguous complaint costs a site visit.
The software problem is not the dispense — it is reconciling charged with delivered, and doing it fast enough that a customer on the phone gets an answer.
How we build it
1. The machine application
A single-purpose application on the machine: product selection, payment, dispense, and a local queue. It assumes the network is down, because sooner or later it is. Every event — coin inserted, card authorised, motor turned, optical sensor triggered — is written to a local append-only log first and published second.
2. The transport
MQTT over TLS with per-device credentials, a last-will message so a machine going quiet is an event rather than silence, and a shadow document holding the configuration the machine should be running.
3. The service
A small ingest service that turns device events into two things: a ledger row (charged / dispensed / refunded, reconciled by transaction id) and a health record (temperature, door state, stock level, firmware version, last seen).
4. The screen the support team actually uses
One page per machine: current state, the last fifty events in plain language, stock by slot, and two buttons that matter — re-dispense and refund — both recorded against the operator who pressed them.
What you would get
- The machine application and its update channel
- An ingest service and event schema you own
- A fleet dashboard, and a single-machine view built for a phone call
- A reconciliation report that finance will accept
Where it gets hard
Clock skew between the machine and the server makes event ordering a lie — so the device stamps a monotonic sequence number, not just a timestamp. Firmware rollout needs a staged channel and a rollback, because a bad update on a fleet is a very expensive lesson. And optical sensors fail open: without a second signal, “dispensed” is an assumption.
